Wika Type 213.53 30 to 0" Hg Industrial Gauge with Bottom Connection, 2 1/2" Dial

Wika Type 213.53 30 to 0
Zoom Image
Representative image only.
Add to Compare

Wika Type 213.53 30 to 0" Hg Industrial Gauge with Bottom Connection, 2 1/2" Dial

Wika | Mfr: 9767002| Item: 6804600

FlexWindow™ option with integrated pressure compensation and 100% case fill

  • Glycerin fill aids readability by dampening needle fluctuations ... READ MORE

£39.41GBP / Each
£47.29GBP (incl VAT)
Add To Cart
+ADD TO LIST

PRODUCT OPTIONS

See All 19 Items in this Product Family

for an additional
£229.84GBP / Each
£275.81GBP (incl VAT)
for an additional
£150.45GBP / Each
£180.54GBP (incl VAT)
Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

£39.41GBP / Each
£47.29GBP (incl VAT)
Add To Cart

Buy It Together

Current Item

Wika Type 213.53 30 to 0" Hg Industrial Gauge with Bottom Connection, 2 1/2" Dial
Wika Type 213.53 30 to 0" Hg Industrial Gauge with Bottom Connection, 2 1/2" Dial
6804600

£39.41GBP / Each
£47.29GBP (incl VAT)
+
Cole-Parmer Pressure Gauge ~ 1/4" NPT(M) process connection; 0 to 10" Water Column
Cole-Parmer Pressure Gauge ~ 1/4" NPT(M) process connection; 0 to 10" Water Column
6835700

£32.36GBP / Each
£38.83GBP (incl VAT)
+
Ashcroft 30052.5 Commercial Gauge with Back Connection, 0 to 15 psi, 2-1/2" Dial
Ashcroft 30052.5 Commercial Gauge with Back Connection, 0 to 15 psi, 2-1/2" Dial
6800802

£42.23GBP / Each
£50.68GBP (incl VAT)
+
Cole-Parmer Utility Pressure Gauge, 2.5" Dia, Bottom Connection; 0-30" Hg
Cole-Parmer Utility Pressure Gauge, 2.5" Dia, Bottom Connection; 0-30" Hg
6835600

£29.12GBP / Each
£34.94GBP (incl VAT)
+
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
1704010

£150.45GBP / Each
£180.54GBP (incl VAT)
+ =
Total Price 326.01 ADD 6 ITEMS TO CART

Customers Also Bought

Product Description

Key Features

  • Glycerin fill aids readability by dampening needle fluctuations
  • Accuracy is ±1.5%
  • 1 year warranty

More About this Item

Gauges feature a copper alloy tube, brass socket, 304 stainless steel case, and plastic lens. All connections are 1/4" NPT(M). Shpg wt 1 lb (0.5 kg).

1 Year Warranty
Specifications
  • Accuracy±2-1-2% full-scale
  • Dial Size (in)2.5
  • Dial Size (mm)64
  • Min Pressure (PSI)0
  • Max Pressure (PSI)14.7
  • Min Temperature (° F)-4
  • Max Temperature (° F)140
  • Min Temperature (° C)-20
  • Max Temperature (DegreeC)60
  • Max Vacuum (" Hg)30
  • Min Vacuum (" Hg)0
  • Liquid FillGlycerin
  • Wetted MaterialsCopper
  • Case304 SS
  • Lens MaterialPolycarbonate
  • Process Connection1/4" NPT(M), lower
  • Unit Of Measurement" Hg
  • DisplayAnalog dial
  • Media CompatibilityGases and liquids compatible with wetted materials
  • Description30 to 0" Hg Industrial Gauge with Bottom Connection, 2 1/2" Dial
  • Warranty1 year
