Wika 4377716 NSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4" NPT(M); 2" Dial

Wika 4377716 NSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4
Zoom Image
Representative image only.
Add to Compare

Wika 4377716 NSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4" NPT(M); 2" Dial

Wika | Mfr: 4377716| Item: 6804907

Manufactured with “lead free” components as defined in the SDWA

£32.44GBP / Each
£38.93GBP (incl VAT)
Add To Cart
+ADD TO LIST

PRODUCT OPTIONS

See All 13 Items in this Product Family

for an additional
£229.84GBP / Each
£275.81GBP (incl VAT)
for an additional
£150.45GBP / Each
£180.54GBP (incl VAT)
Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

£32.44GBP / Each
£38.93GBP (incl VAT)
Add To Cart

Buy It Together

Current Item

Wika 4377716 NSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4" NPT(M); 2" Dial
Wika 4377716 NSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4" NPT(M); 2" Dial
6804907

£32.44GBP / Each
£38.93GBP (incl VAT)
+
Cole-Parmer Digital Pressure Gauge, Vacuum to 100 psi, with 1/8" NPT(M) Connections
Cole-Parmer Digital Pressure Gauge, Vacuum to 100 psi, with 1/8" NPT(M) Connections
6895025

£50.72GBP / Each
£60.86GBP (incl VAT)
+
Wika 9833557 Bourdon Tube Pressure Gauge, 0 to 200 psi, 2.5" Dial, 1/4 NPT(M)
Wika 9833557 Bourdon Tube Pressure Gauge, 0 to 200 psi, 2.5" Dial, 1/4 NPT(M)
6843483

£95.20GBP / Each
£114.24GBP (incl VAT)
+
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
1704010

£150.45GBP / Each
£180.54GBP (incl VAT)
+ +
Wika Type 213.53 0 to 100 psi Industrial Gauge with Back Connection, 2 1/2" Dial
Wika Type 213.53 0 to 100 psi Industrial Gauge with Back Connection, 2 1/2" Dial
6804630

£39.41GBP / Each
£47.29GBP (incl VAT)
+
Marsh Bellofram M1R1NM Miniature Regulator 0 To 60 PSIG; 1/8" NPT(F)
Marsh Bellofram M1R1NM Miniature Regulator 0 To 60 PSIG; 1/8" NPT(F)
6882650

£26.80GBP / Each
£32.16GBP (incl VAT)
+
Industrial Pressure Gauge, 30" to 0" Hg
Industrial Pressure Gauge, 30" to 0" Hg
6808044

Call For Price
=
Total Price 417.60 ADD 8 ITEMS TO CART

Customers Also Bought

Product Description

Key Features

  • Made in the USA
  • Special lead-free, Silver-solder for all wetted parts
  • 1 year warranty

More About this Item

These NSF certified gauges are manufactured in accordance with NSF/ANSI 61, for lead-free content, and come in a wide range of models, sizes and configurations. The guages have special dials with NSF logo on the dial to indicate compliance. These NSF gauges are available in custom versions and configurations. Call our Application Specialists to find out about custom versions of the gauge.

NSF international certified1 Year Warranty
Specifications
  • Accuracy±3-2-3% full-scale (ANSI/ASME Grade B)
  • Dial Size (in)2
  • Dial Size (mm)51
  • Min Pressure (PSI)0
  • Max Pressure (PSI)160
  • Min Temperature (° F)-4
  • Max Temperature (° F)140
  • Min Temperature (° C)-20
  • Max Temperature (DegreeC)60
  • Wetted MaterialsCopper alloy
  • CaseCopper alloy
  • Process Connection1/4" NPT(M), lower
  • DisplayAnalog dial
  • Media CompatibilityGases and liquids compatible with wetted materials
  • DescriptionNSF-Certified Pressure Gauge, 0 to 160 PSI, Bottom Mount 1/4" NPT(M); 2" Dial
  • Warranty1 year
