United Electric H100-190 Pressure Switch 5/30PSI Temperature Pressure Switch

Name: United Electric H100-190 Pressure Switch 5/30PSI Temperature Pressure Switch
Brand: United Electric
SKU: 6845702
Price: 243.92 GBP
Availability: OutOfStock

Zoom Image

Representative image only.

Add to Compare

United Electric H100-190 Pressure Switch 5/30PSI Temperature Pressure Switch

United Electric | Mfr: H100-190| Item: 6845702

2 year warranty ... READ MORE

£243.92GBP / Each

£292.70GBP (incl VAT)

Add To Cart

+ADD TO LIST

PRODUCT OPTIONS

See All 5 Items in this Product Family

Include Calibration Services

InnoCal A2LA ISO17025 Accredited Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

£229.84GBP / Each

£275.81GBP (incl VAT)

InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

£150.45GBP / Each

£180.54GBP (incl VAT)

Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

Product Description

Key Features

2 year warranty

More About this Item

FEATURES

Legendary UE Reliability
Wide selection of adjustment ranges
Internal reference scales and adjustment lock
Enclosure design permits safe and easy access for wiring
Choice of 1/2" NPTF electrical connection or knockouts
Die cast aluminum enclosure, epoxy powder coated, gasketed, captive screws

Specifications

Accuracy±1.5% of adjustable range
Min Pressure (PSI)5
Max Pressure (PSI)30
Wetted Materials316 SS
Casealuminum
Process Connection1/2" NPT(F)
Electrical Connections1/2" NPT(F); two 7/8" diameter knockouts
Electrical terminationScrew terminals
Switch output15 A at 125/250 VAC (resistive), NO or NC
OutputSPDT
Enclosure RatingNEMA 4X
Media CompatibilityGases and liquids compatible with wetted materials
DescriptionPressure Switch 5/30PSI Temperature Pressure Switch
Warranty2 year
