Travel is indicated on the control unit display, with output via USB. An internal scale utilizing Renishaw technology produces significantly higher accuracy than with conventional rotary encoderbased designs. Backlash and nonlinearity are virtually eliminated.
Requires:
- Field hardware installation required (if not ordered at the same time as test stand).
- Series 7 or 5 force gauge with load cell.
If data output to a PC is also wanted:
-25303-16 (09-1214) and 25303-17 (09-1158) cables
