Cole-Parmer Pressure Gauge, Viton diaphragm seal, 1/2" NPT(F); 0 to 30 psi

Cole-Parmer Pressure Gauge, Viton diaphragm seal, 1/2
Zoom Image
Representative image only.
Add to Compare

Cole-Parmer Pressure Gauge, Viton diaphragm seal, 1/2" NPT(F); 0 to 30 psi

Cole-Parmer | Item: 6800039

Ideally suited for use in ultra-pure water and aggressive chemicals

  • Diaphragm seal and gauge molded into one unit ... READ MORE

£101.43GBP / Each
£121.72GBP (incl VAT)
Add To Cart
+ADD TO LIST

PRODUCT OPTIONS

See All 22 Items in this Product Family

for an additional
£229.84GBP / Each
£275.81GBP (incl VAT)
for an additional
£150.45GBP / Each
£180.54GBP (incl VAT)
Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

£101.43GBP / Each
£121.72GBP (incl VAT)
Add To Cart

Buy It Together

Current Item

Cole-Parmer Pressure Gauge, Viton diaphragm seal, 1/2" NPT(F); 0 to 30 psi
Cole-Parmer Pressure Gauge, Viton diaphragm seal, 1/2" NPT(F); 0 to 30 psi
6800039

£101.43GBP / Each
£121.72GBP (incl VAT)
+
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%
1704010

£150.45GBP / Each
£180.54GBP (incl VAT)
+
Cole-Parmer Digital Pressure Gauge, 0 to 1000 psi, 2.5" dia, 1/4" NPT(M)
Cole-Parmer Digital Pressure Gauge, 0 to 1000 psi, 2.5" dia, 1/4" NPT(M)
6895055

£158.28GBP / Each
£189.94GBP (incl VAT)
=
Total Price 410.16 ADD 3 ITEMS TO CART

Customers Also Bought

Product Description

Key Features

  • Diaphragm seal and gauge molded into one unit
  • Glycerine filled seal is standard
  • Gauge case is dry but fillable
  • 1 year warranty

More About this Item

These gauges are molded from a harder blend of polymers, making them more resistant to cracking or breaking during installation and use. Gauges feature brass Bourdon tube and internals; diaphragm fill is glycerin. White PVDF gauges feature a PTFE diaphragm seal; black polypropylene (PP) gauges feature a Viton® diaphragm seal. All gauge casings are dry but can be filled.

1 Year Warranty
Specifications
  • Accuracy±1.5% full-scale
  • Dial Size (in)2.5
  • Dial Size (mm)64
  • Min Pressure (PSI)0
  • Max Pressure (PSI)30
  • Min Temperature (° F)-4
  • Max Temperature (° F)140
  • Min Temperature (° C)-20
  • Max Temperature (DegreeC)60
  • Diaphragm FillGlycerin
  • Wetted MaterialsViton®
  • CasePolypropylene
  • Lens MaterialAcrylic
  • Process Connection1/2" NPT(F)
  • Unit Of Measurementpsi, bar, kPa
  • DisplayAnalog dial
  • Media CompatibilityGases and liquids compatible with wetted materials
  • DescriptionPressure Gauge, Viton diaphragm seal, 1/2" NPT(F); 0 to 30 psi
  • Warranty1 year
