Ashcroft 1009 Glycerin-Filled SS Pressure Gauge, 2.5" Dial, 1/4" NPT(M) Lower Connection, 0 to 600 psi
Representative image only.
Ashcroft 1009 Glycerin-Filled SS Pressure Gauge, 2.5" Dial, 1/4" NPT(M) Lower Connection, 0 to 600 psi
Liquid-filled to dampen vibration
- Meets ASME B40.100 specifications ... READ MORE
£90.85GBP / Each
£109.02GBP (incl VAT)
for an additional
£229.84GBP / Each
£275.81GBP (incl VAT)
for an additional
£150.45GBP / Each
£180.54GBP (incl VAT)
£90.85GBP / Each
£109.02GBP (incl VAT)
Buy It Together
Current Item
Ashcroft 1009 Glycerin-Filled SS Pressure Gauge, 2.5" Dial, 1/4" NPT(M) Lower Connection, 0 to 600 psi
6802206
£90.85GBP / Each
£109.02GBP (incl VAT)
1704010
£150.45GBP / Each
£180.54GBP (incl VAT)
Customers Also Bought
-
![Ashcroft® Stainless Steel Industrial Process Gauge]( "Ashcroft® Stainless Steel Industrial Process Gauge")
£87.12 - £141.04GBP / Each£104.54 - £169.25GBP (incl VAT)
Product Description
Key Features
- Meets ASME B40.100 specifications
- Corrosion resistant SS case
- Dry gauges are field fillable
- PowerFlex™ movement provides superior resistance to shock, vibration and pulsation
- True Zero™ reduces reading errors by using “zero box” instead of conventional dial pins
- MSL helium leak tested to 1X10-6 scc/s
- Ventable fill plug
- 5 year warranty
More About this Item
The Ashcroft® type 1009 Industrial Pressure Gauge is ideal for resisting chemical, weather or corrosion effects. Providing durability, reliability and performance, it is well-suited for aggressive process media applications. A good choice for satisfying many application and installation requirements. Available in 2.5" and 3.5" dial sizes, Ashcroft Duralife pressure gauges are liquid fillable and field convertible for panel mounting. Both zero and span adjustments are standard.
Specifications
- AccuracyASME B40.100, Grade 1A, +1% of span (Dry), +1.5% of span (Liquid-filled)
- Dial Size (in)2.5
- Dial Size (mm)63
- Min Pressure (PSI)0
- Max Pressure (PSI)600
- Liquid FillGlycerin
- Wetted Materials316 stainless steel
- Case304 stainless steel
- Lens MaterialPolycarbonate
- Process Connection1/4" NPT(M), lower
- Unit Of Measurementpsi
- DisplayAnalog dial
- Media CompatibilityGases and liquids compatible with wetted materials
- DescriptionGlycerin-Filled Stainless Steel Pressure Gauge, 2.5" Dial, 1/4" NPT(M) Lower Connection, 0 to 600 psi
- Warranty5 years
