Dynasonics DTTSDP-020-N-000 Ultrasonic Flow Transducer for 1/2" ANSI Pipe, 2 to 38 GPM (8 to 144 LPM)

Dynasonics DTTSDP-020-N-000 Ultrasonic Flow Transducer for 1/2
Zoom Image
Representative image only.
Add to Compare
Dynasonics – Mfr # DTTSDP-020-N-000 – Item # UY-32617-26
Write a Review
No need to shut down the process for installation or maintenance due to clamp-on sensor design
  • Bidirectional flow measurement system
  • Large, easy-to-read digital display
  • Rate and total backlit display
  • 4 to 20 mA output
  • RS-485 Modbus network connection
MORE +

PRODUCT OPTIONS

See All 13 Items in this Product Family

£534.00GBP / Each
£640.80GBP (incl VAT)
Add To Cart
+ADD TO LIST

SPECS & DESCRIPTION

Specifications & Description

  • Accuracy±1% of reading or ±0.01 ft/sec (0.003 m/s), whichever is greater
  • Material HousingPowder-coated aluminum, PP, SS, polyurethane, nickel-plated steel mounting brackets
  • Wetted MaterialsCPVC, Ultem®, nylon, and PVC
  • Min Operating Temperature (° F)-40
  • Min Operating Temperature (° C)-40
  • Max Operating Temperature (° F)185
  • Max Operating Temperature (° C)85
  • Pipe Size½" ANSI
  • Fluid TypeWater
  • Output (mA)Yes
  • Output4 to 20 mA
  • Display Type2-line LCD, LED backlight. Top row: 7 segment 0.7"H. Botton row: 0.35"H
  • CommunicationsRS-485
  • Enclosure RatingIP65
  • DescriptionUltrasonic Flow Transducer for 1/2" ANSI Pipe, 2 to 38 GPM (8 to 144 LPM)

Key Features

  • Bidirectional flow measurement system
  • Large, easy-to-read digital display
  • Rate and total backlit display
  • 4 to 20 mA output
  • RS-485 Modbus network connection
  • Remote totalizer reset
  • 0 to 1000 Hz rate pulse and dual alarm output
  • USB programming port with software included
  • Rugged, aluminum enclosure ensures a long service life in harsh environments
  • Totalizer options include forward, reverse, and net total
  • Use to measure clean liquids as well as those with small amounts of suspended solids or aeration

More About this Item

Order Flowmeter 32617-24 with your transducer for a complete system!
Ultrasonic flowmeters clamp onto the outside of pipes and do not contact the internal liquid. The technology has inherent advantages over alternate devices including low-cost installation, no pressure head loss, no moving parts to maintain or replace, no fluid compatibility issue, and a large, bidirectional measuring range that ensures reliable readings even at very low and high flow rates. Flowmeters are available in a variety of configurations — select a meter with features suitable to meet your particular application requirements.

REVIEWS

Q&A

Do you have questions about this product?

Get answers from real customers and in-house experts with AnswerBox.

1 Question | 1 Answer
Displaying question 1

  • Q:

    Can this instrument measure air flow with air at room temperature conditions? Can I use PVC pipe?
    If this instrument is not designed to measure air flow do you have one that can?
    If yes please quote the instrument the pipe size is 1/2 inch and 1 inch.
    Asked on 10/20/2015 by rene from Burbank CA

    1 answer

    • STAFF EXPERT

      A:

      This flow meter is designed to measure the flow of fluid with suspended solids or gas bubbles. All ultrasonic flow meters are designed for liquids, not gasses as they need something (such as the solid) to bounce the signal off as as the flow detection method.

      Answered on 10/20/2015 by Danielle from Technical Support
